6-Port Double Row Staggered Square Tooth Water Divider
Category ：
Key Word ：manifold
- PRODUCT DESCRIPTION
-
- 商品名称: 6-Port Double Row Staggered Square Tooth Water Divider
Staggered Square Tooth Water Divider
Diagram of water injection installation
Description
Product Name:
6-Port Double Row Staggered Square Tooth Water Divider
Product specifications:
DN15-DN300
Material:
Stainless steel 304, 316L
Product size:
see attached diagram
Application:
Widely applicable, suitable for low-pressure fluid transportation in civil applications such as hot and cold water, heating, fire protection, gas, etc
serial number
Product Specifications
Main water pipe size (mm)
water inlet
diversions
Number of outlets
Distance between water outlets (mm)
1
DN32x20xN
Ф40*1.2
11/4 "external teeth
3/4 "external teeth
N
150、180
2
DN40x20xN
Ф50.8*1.2
11/2 "external teeth
3/4 "external teeth
N
150、180
3
DN50x20xN
Ф60.3*1.5
Ф50.8*1.2
2 "external teeth
3/4 "external teeth
N
150、180
4
DN65x20xN
Ф76.1*1.5
21/2 "external teeth
3/4 "external teeth
N
200
5
DN25x20xN
40*1.2
1 "external teeth
1/2 "external teeth
N
50
Physical display
Customer feedback and packaging and transportation
Double card compression technology originating from Germany, the true green pipeline of the 21st century
01
Piping material dropping:
Measure the size of piping, use electric mechanical toothed saws or manual cutters to cut pipes, and prohibit toothless cutting.
02
Cleaning burrs:
Use specialized tools to remove burrs on the end face of the pipe, or use tools such as files and scrapers to remove them.
03
Check the sealing ring:
Check if the sealing ring is aligned correctly Fit the groove?
04
Insert the tube
The depth of the pipe inserted into the fitting socket should match the marked line, and the adjustment amount should be less than 3mm. Please ensure the insertion depth of the pipe and do not damage the sealing ring inside the fitting.
05
Compression operation
Use specialized tools for crimping operations.
06
Finished product
The final product should have a neat and even compression section.
